AVENTOS HK-XS
Virtually tool-free assembly
The assembly of AVENTOS HK-XS components is virtually tool free. Adjust the lift mechanism precisely to the weight and size of the front and AVENTOS HK-XS will open, close and hold with reliable ease. Combine it with CLIP top BLUMOTION hinges and the small stay lift will close softly and effortlessly.
Easy assembly and adjustment
Symmetrical fittings
AVENTOS HK-XS’s lift mechanism, front and cabinet fixing brackets are all symmetrical.
Soft close
Combine AVENTOS HK-XS with CLIP top BLUMOTION hinges for soft and effortless closing.
CLIP mechanism
The tried and tested CLIP mechanism is tool-free, quick and easy.
Infinitely variable power setting
Use a cordless screwdriver to precisely adjust the lift mechanism to the weight of the front. And the front will hold in any position.
3-dimensional adjustment
Easy 3-dimensional adjustment produces perfect gap alignment.
Assembly instructions
Assembly videos
AVENTOS HK-XS short film
This product snippet shows the motion and the variable stop of AVENTOS HK-XS.
AVENTOS HK-XS
This video demonstrates the simple assembly of AVENTOS HK-XS, the lift mechanism adjustment and the three-dimensional adjustment options using CLIP top BLUMOTION.
AVENTOS HK-XS adjustment options
The adjustment options for height, side and depth of the front are shown in this sequence.
AVENTOS image video
Background information on the development of AVENTOS
Assembly devices
Blum offers a wide range of drilling and insertion machines, assembly devices and templates to ensure that the assembly of Blum products is accurate, quick and easy, for optimal performance requires precise assembly.
