TANDEM
Easy assembly and installation
TANDEM gives you an extensive range of options. and yet assembly is always the same.
Assembly with locking device feature
The TANDEM locking device allows you to attach and remove the drawer in no time. An integrated lift-off stop prevents accidental detachment. Height adjustment allows differences of up to 3 mm to be balanced out. The front can be aligned parallel to the cabinet front edge using the tilt adjustment feature.
Height adjustment
Tilt adjustment for full extensions
Side adjustment
Assembly with hook and peg feature
Place the drawer on the runner, pull forwards, done. The lift-off stop prevents accidental detachment from the runner. Fine tuning takes just a few steps: up to 2.5 mm can be corrected using the tool-free height adjustment feature, while the integrated front tilt adjustment feature allows for effortless alignment of the front.
Side adjustment
Height adjustment
Tilt adjustment for full extensions
Lift-off stop
Support every step of the way
We offer bespoke services and assembly devices for the TANDEM runner system. We support you along the entire process chain: our E-SERVICES help you to plan, design and choose products around the clock. In addition to drilling and insertion machines, we also offer special drilling templates for furniture production, such as for TANDEM with the hook and peg feature or for the TANDEM front adjuster.
Installation instructions
Phụ kiện TANDEM
Ray trượt TANDEM với tính năng khóa ray
PDF | 658 KB | 07-13-2023
Ray trượt TANDEM với tính năng ngạc và chốt
PDF | 573 KB | 07-13-2023
TANDEM 19 mm
PDF | 476 KB | 07-13-2023
TANDEM với TIP-ON tích hợp - tính năng móc và chốt
PDF | 2 MB | 09-28-2023
TANDEM với TIP-ON tích hợp - đặc điểm khóa ray
PDF | 2 MB | 09-27-2023
Thanh giằng ray TANDEM mở 3/4
PDF | 1 MB | 06-15-2023
Thanh giằng ray TANDEM mở toàn phần
PDF | 2 MB | 06-15-2023
Assembly devices
We offer bespoke services and assembly devices for the TANDEM runner system. We support you along the entire process chain: our E-SERVICES help you to plan, design and choose products around the clock. In addition to drilling and insertion machines, we also offer special drilling templates for furniture production, such as for TANDEM with the hook and peg feature or for the TANDEM front adjuster.
