TIP-ON BLUMOTION for MOVENTO
Easy manufacturing and assembly
Pull-outs and drawers that are to be equipped with TIP-ON BLUMOTION for MOVENTO are made as normal. No additional work is required. Blum’s practical templates make manufacturing and assembly easy.
Manufacturing, assembly and adjustment
Standard cabinets and drawers
TIP-ON BLUMOTION can be implemented with standard cabinets and fronts. No modifications are needed.
Same drilling positions
For TIP-ON BLUMOTION, you can use the same drilling positions that you would normally use for MOVENTO.
Simple, tool-free assembly
The TIP-ON BLUMOTION unit can be assembled without tools, as can all other components.
Precise front gap alignment
Use the adjustment template to adjust the front gap to 2.5 mm. It’s precise and easy.
Synchronisation
The synchronisation feature enlarges the trigger range and improves the TIP-ON BLUMOTION function. Synchronisation options are available for different internal cabinet widths and can be mounted without tools.
Internal cabinet widths starting from 314 mm
TIP-ON BLUMOTION units for internal cabinet widths of 314 mm or more are synchronised with synchronisation adapters and a synchronisation linkage.
Tool-free assembly
The symmetrical synchronisation linkage is clipped onto the TIP-ON BLUMOTION unit without tools.
Assembly instructions
Videos
Assembly devices
Blum offers a wide range of drilling and insertion machines, assembly devices and templates to ensure that the assembly of Blum products is accurate, quick and easy, for optimal performance requires precise assembly.
